TSC TTP-368MT Barcode Label Printer

Model: TSC TTP-368MT Category: TSC Industrial Printers

TSC TTP-368MT Barcode Label Printer (Wide Format) - 300 dpi direct thermal and thermal transfer printer, 6.6" print width. 6" wide labels, 300 dpi. Supplied with installation, labels, ribbons and service support by Mindw...

Best price on request

Send the availability form. If the product is in stock, we confirm our best price and bill it with a GST invoice.

WhatsApp Call
Download datasheet (PDF)
  • Genuine products with warranty support
  • Installation & service centre in Dwarka, Delhi
  • Pan-India delivery, GST invoice
Labels & ribbons for this printerFrom Mindware - any size, best prices

Full Specifications

Printing
Resolution12 dots/mm (300 DPI)
Print methodThermal Transfer & Direct Thermal
Max. print speed254 mm (10”)/second
Max. print width168 mm (6.61”)
Max. print length6,604 mm (260”)
Hardware
Processor32-bit RISC CPU
Memory512 MB Flash memory; 256 MB SDRAM; SD Flash memory card reader for Flash memory expansion, up to 32 GB
SensorsTransmissive gap sensor (position adjustable); Black mark reflective sensor (position adjustable); Ribbon encode & ribbon end sensor; Head open sensor
Controls and display16 bits Color, 480 x 272 pixels, with back lights, Resistive Touch Screen; 1 power switch, 6 buttons (Menu, Pause, Feed, Up, Down, Select)
Real-time clockStandard
EnclosureDie-cast aluminum frame/Metal cover with large clear media view window
Connectivity
InterfacesRS-232; Centronics; USB 2.0; Internal Ethernet, 10/100 Mbps; USB host, for scanner or PC keyboard; GPIO (factory option); Bluetooth (user option)
Labels and media
Label roll capacity208.3 mm (8.2”) OD
Media typeContinuous, die-cut, fan-fold, tag, notched, black mark (outside wound)
Media width50.8 ~ 172.7 mm (2” ~ 6.8”)
Media thickness0.06 ~ 0.254 mm (2.36 ~ 10 mil)
Media core diameter76.2 mm (3”)
Label length10 ~ 6,604 mm (0.39” ~ 260”)
Ribbon
Ribbon capacity450 meter long, max. OD 81 mm, 1” core (Ink coated outside/inside)
Ribbon width50.8 mm ~ 178 mm (2” ~ 7”)
Software and fonts
Printer languagesTSPL-EZ™ (Compatible to EPL, ZPL, ZPL II)
Internal fonts8 alpha-numeric bitmap fonts; Monotype Imaging® true type font engine with one CG Triumvirate Bold Condensed scalable font
Barcodes1D bar code Code 39, Code 93, Code 128UCC, Code 128 subsets A.B.C, Codabar, Interleave 2 of 5, EAN-8, EAN-13, EAN-128, UPC-A, UPC-E, EAN and UPC 2(5) digits add-on, MSI, PLESSEY, POSTNET, China POST, GS1 DataBar, Code 11; 2D bar code PDF-417, Maxicode, DataMatrix, QR code, Aztec
Font and barcode rotation0, 90, 180, 270 degree
Size and power
Dimensions355 mm (W) x 337 mm (H) x 520 mm (D); 13.98” (W) x 13.27” (H) x 20.47” (D)
Weight23 kg (50.71 lbs)
Power supplyInternal universal switching power supply; Input: AC 100-240V, 3.0A, 50-60Hz; Output: DC 24V, 8.33A, 200W
Environment and compliance
Operating environmentOperation: 5 ~ 40°C, 25 ~ 85% non-condensing; Storage: -40 ~ 60°C, 10 ~ 90% non-condensing
Safety regulationFCC Class A, CE Class A, CCC
Manufacturer warrantyPrinter: 2 years; Print head: 25 km (1 million inches) or 12 months which comes first; Platen: 50 km (2 million inches) or 12 months which comes first
Options
Factory optionsGPIO interface
Dealer optionsPeel-off kit (include internal rewind & peel off module); Heavy duty cutter (full cut)
User optionsBluetooth module (serial interface); KP-200 Plus keyboard display unit; KU-007 Plus programmable smart keyboard

From the TSC datasheet. Specifications can change with the model version. Warranty terms for India are confirmed on your quotation.

Description

TSC TTP-368MT Barcode Label Printer (Wide Format) - 300 dpi direct thermal and thermal transfer printer, 6.6" print width. 6" wide labels, 300 dpi. Supplied with installation, labels, ribbons and service support by Mindware, New Delhi.

Features

  • Print method: Direct thermal and thermal transfer
  • Resolution: 300 dpi
  • Max print width: 6.6"
  • Series: Wide Format
  • Ideal for: 6" wide labels, 300 dpi
